SPECIFICATION

• Network Interface : Standard RJ45 input

• Support Protocol : TCP/IP,UDP,IGMP (Multicast)

• Audio Format : MP3

• Sampling Rate : 8K~48KHz

• Transmission rate : 100Mbps

• Audio Mode : 16 bit  CD quality

• Display Size : 7-inch

• Screen Resolution : 800 x 480 Pixel

• Screen Type : 65K Color DGUS Screen

• Keyboard Type : virtual QWERTY Keyboard

• Keyboard Input Type : Touch screen

• Inscribed speaker impedance and power rating : 4Ω,2W

• THD : ≤1%

• Frequency response : 80Hz~16KHz  +1dB/-3dB

• SNR : >65dB

• PHONE OUT output impedance and power rating : 16Ω,2mW

• LINE OUT Output Level : 1000mV Industry standard wire terminals

• LINE OUT Output Impedance : 470Ω

• LINE IN Input Sensitivity : 350mV Industry standard wire terminals

• MIC Input Sensitivity(Unbalance) : 10mV

• Short-circuit input : Dry contact input

• Short-circuit output : Max 1A/30VDC Dry contact input

• Working Temperature : 5℃~40℃

• Working Moisture : 20%~80%Relative humidity, without condensation

• Working Consumption : ≤6W

• Power Input : ~190-240V 50-60Hz (power adapter); DC24V/2A

• Size : 200×160×60 mm

• Weight : 1.2Kg

• System software : supports SIP standard protocol
